Full Undirectional Airflow Weighing Booth 0.45m/S For Protection

    Buy cheap Full Undirectional Airflow Weighing Booth 0.45m/S For Protection from wholesalers

    Buy cheap Full Undirectional Airflow Weighing Booth 0.45m/S For Protection from wholesalers
    • Buy cheap Full Undirectional Airflow Weighing Booth 0.45m/S For Protection from wholesalers
    • Buy cheap Full Undirectional Airflow Weighing Booth 0.45m/S For Protection from wholesalers
    • Buy cheap Full Undirectional Airflow Weighing Booth 0.45m/S For Protection from wholesalers

    Full Undirectional Airflow Weighing Booth 0.45m/S For Protection

    Ask Lasest Price
    Brand Name : LENGE
    Model Number : LWR 75 - 200180
    Certification : CE/ISO
    Price : Negotiate
    Payment Terms : T/T, L/C
    Supply Ability : 100 Sets per Month
    Delivery Time : 15-20 Days
    • Product Details
    • Company Profile

    Full Undirectional Airflow Weighing Booth 0.45m/S For Protection

    0.45m/s Full Undirectional Airflow Weighing Booth For Protection

    LENGE Dispensing Booth is an advanced containment system which provides controlled negative pressure environments to maximize personnel protection during weighing and sampling process. LENGE provide standard configurable designs which is able to adapt to various weighing and sampling requirements.


    Characteristics & Features:

    • Cross contamination control through negative pressure environment option.

    • Full unidirectional airflow provides superior aseptic work zones.

    • Fully welded single piece SUS304 internal chambers with rounded covered corners.

    • GMP modular design with minimized joints and seams.

    • Gel seal HEPA filters, HEPA/ULPA gel sealed design is better than conventional gasket sealed.

    • All components meet or exceed applicable safety requirements.


    Technical Specifications & Parameters:


    Material

    SUS 304/316L stainless steel

    Filter Module

    Pre-filter, comport filter, HEPA filter

    Core Part

    Air Blower

    Model No.

    LWR 13-120060

    LWR 34-150120

    LWR 75-200200

    LWR 112-300200

    LWR 186-400250

    Outer Size
    W×D×H (mm)

    1300×1200×2570

    1600×1800×2570

    2100×2800×2570

    3100×2800×2570

    4100×3300×2570

    Inner Size
    W'×D'×H' (mm)

    1200×600×2000

    1500×1200×2000

    2000×2000×2000

    3000×2000×2000

    4000×2500×2000

    Rated Air Velocity
    (m/s)

    0.45±20%

    Cleanliness Class

    Same as the background area

    Power Supply

    380V, 50Hz

    Power (kW)

    0.8

    2

    4

    4

    7.5

    Note: The specifications listed in above table are only for customer’s reference. It is mostly designed and manufactured according to customer’s URS.
    Containment System:

    • Main Stream - The opening provides an airflow velocity of 0.45 m/s.

    • Standard controls suitable for safe area applications.

    • RH/Temperature sensor.

    • HEPA filter to provide high level of filtration.

    • Emergency stop.

    • HEPA fan module provides laminar flow of particlefree air (measured at 0.3µm particles) to meet clean room requirements—99.995% efficient ULPA filters also available.

    • Filter Module

    • —— Pre filter -- Panel filter G4

    • —— Comfort filter -- Bag filter F8

    • —— HEPA filter -- Gel sealed mini-pleated HEPA filter H14

    • Fan modules includes 99.99% efficient HEPA filter to ensure clean working conditions

    • 380 V power supply

    Product Outline Design:

    称量


    称量室

    Full Undirectional Airflow Weighing Booth 0.45m/S For Protection
    LENGE purification has a perfect high-quality service team, which can make reasonable purification plan according to the customer's investment and operation cost to meet the customized needs. There are business personnel all over China to help customers effectively solve their needs. We have perfect after-sales service and professional technical personnel for on-site guidance and training.
